Solar U pipe collector

Name: Solar U pipe collector
Brand: Raven New Energy
Price: 300 USD

Wholesale Solar U pipe collector from china suppliers

Brand Name : Raven New Energy

Model Number : RNE-UCA-15

Certification : CE

Place of Origin : CHINA

MOQ : 1SET

Price : 300USD/SET FOB

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 2000 Sets per month

Delivery Time : 15 days

Packaging Details : cartons , plywood box

Tube number : 15 tubes

solar collector type : U pipe solar collector

solar vacuum tube : 58/1800 three target

stand frame : Aluminum alloy 2.0mm thick , 30/ 45 degree

Manifold case : Aluminum alloy 2.0mm

Insulation : rock wool 40MM

Warranty : 5 years

working pressure : 8bar

Contact Now

U pipe solar collector

Solar U pipe collector

Specialty:

In each vacuum tube there is a U pipe with direct flow-through that is connected to the header pipe inside manifold. This U pipe is seamed in an aluminum heat transfer fin in the interior of vacuum tube that transmits the heat FROM the interior tube to the U pipe.
Solar radiation permeates the outer glass tube and is captured on the outside of inner glass tube by highly selective sputter layer. The captured solar radiation is transmitted to flush-contact aluminum shield and then copper pipe filled with heat transfer fluid. The 360°aluminum heat transfer fin assures the fastest energy transfer.

Technical specification:

1. Outer manifold material: Aluminum alloy or SUS304-2B stainless steel

2. Header Pipe material: Copper

3. Insulation material: Rock wool

4. U pipe material: Copper

6. Frame material: Aluminum alloy or SUS304-2B stainless steel

7. Seal material: Stabilized high temperature silicon

8. Vacuum tube material: borosilicate glass 3.3; AL-SS-CU absorb coating

9. Collector mounting: flat roof or inclined roof

10. Working pressure: 6 bar

11. Testing pressure: 12bar

Solar U pipe collector

Solar U pipe collector Images
